Bypass of the cardia with a stent results in gastroesphageal reflux. In order to prevent the latter and thereby minimise the risk of bronchopulmonary aspirations, the Anti-Reflux Esophageal Stents from MICRO-TECH is equipped with a unique valve system.
The revolutionary aspect of the valve is its 2-way function which imitates the human protective mechanism perfectly. On the one hand, it allows food and liquids to enter the stomach unimpeded and reliably prevents reflux. On the other, it opens in the oral direction in case of excessive pressure. The patient can therefore obtain relief by vomiting in spite of the valve. The valve is particularly flexible and, at the same time, highly resistant to gastric acid.
Innovative 1-way valve system
Self-expanding
Nitinol mesh with atraumatic ends
Excellent positional stability
High radial force
Resistant and elastic covering
High radiopacity
Extraction threads for removal and repositioning
Compatible guide-wire up to 0.035 inches
Anti-Reflux Esophageal Stents | ||||||
REF | Stent | Delivery System | ||||
Body O.D. (mm) | Expanded Length (mm) | Catheter O.D. (Fr/mm) | Working Length (mm) | Packaging | Repositionable | |
Anti-Reflux Esophageal Stents Partially-Covered | ||||||
ST21-112-18.100 | 18 | 100 | 24/8 | 650 | 1/Box | \ |
ST21-112-20.100 | 20 | 100 | 24/8 | 650 | 1/Box | \ |
Anti-Reflux Esophageal Stents Fully-Covered | ||||||
ST21-114-18.100 | 18 | 100 | 24/8 | 650 | 1/Box | \ |
ST21-114-20.100 | 20 | 100 | 24/8 | 650 | 1/Box | \ |
