Biliary Stents

Name: Biliary Stents
Brand: MICRO-TECH (Nanjing) Co., Ltd.

The Biliary Stent is preloaded on the delivery system for ERCP or PTCD. The stent for ERCP is placed through the working channel of the endoscope. The system is introduced into the biliary duct through the papilla under visual control.

KEY BENEFITS

self-expanding

available for TTS and PTCD
Nitinol wire mesh with atraumatic ends
release under visual endoscopic control
excellent position stability
high radiopacity
compatible guide-wire up to 0.035 inches

CATALOG

SPECIFICATION

Biliary stent non-covered
REF	Stent		Delivery System		Packaging
	Body O.D. (mm)	Expanded Length (mm)	Catheter O.D. (Fr/mm)	Working Length (mm)
ST03-001-10.040	10	40	8/2.7	1800	1/Box
ST03-001-10.060		60
ST03-001-10.080		80
ST03-001-10.100		100
Biliary stent partially-covered
REF	Stent		Delivery System		Packaging
	Body O.D. (mm)	Expanded Length (mm)	Catheter O.D. (Fr/mm)	Working Length (mm)
ST03-002-10.040	10	40	9/3.0	1800	1/Box
ST03-002-10.060		60
ST03-002-10.080		80
ST03-002-10.100		100
Biliary stent fully-covered
REF	Stent		Delivery System		Packaging
	Body O.D. (mm)	Expanded Length (mm)	Catheter O.D. (Fr/mm)	Working Length (mm)
ST03-004-10.040	10	40	9/3.0	1800	1/Box
ST03-004-10.050
ST03-004-10.060		60
ST03-004-10.080		80
ST03-004-10.100		100

Click to see the detailed Specifications
